hypercurve

hypercurve

hypercurve is the planar curved-topology crate for the Hyper geometry stack. It owns line, circular-arc, polynomial Bezier, rational-conic, contour, region, boolean-boundary, offset, fitting, flattening, and prepared-query surfaces over hyperreal::Real values.

The crate is not yet a complete general boolean or offset engine. It is already useful as a native exact-aware curve model and as the place where unresolved tangent, overlap, root-isolation, trimming, and boundary cases stay explicit instead of being hidden by display polylines.

WASM Demo

The deployed WASM app is available at https://timschmidt.github.io/hypercurve/.

Hyper Ecosystem

hypercurve is the 2D curved-geometry layer.

• hyperreal: exact scalar values for curve coordinates and parameters.
• hyperlimit: exact predicate policy for sidedness, incidence, and sign decisions.
• hyperlattice: vector and transform facts used by higher geometry and domain crates.
• hypertri: line-only triangulation target for polygonalized or straight-edge regions.
• hypermesh: 3D mesh topology that consumes planar arrangements and triangulated face regions.
• hyperbrep: BREP trims and planar face boundaries that should preserve curve evidence before tessellation.
• hypersdf: implicit-field consumers and preview extraction boundaries.
• hypersolve: Bernstein, interval, and root isolation support for algebraic subproblems.
• hyperpath: routing, CAM, offset, tangent, and swept-path carriers.
• hypervoxel: voxel/process consumers for flattened or certified region evidence.
• hyperphysics: physical shape and support consumers.
• hypercircuit: circuit context for PCB paths and geometry-derived fixtures.
• hyperparts: part, package, and footprint geometry handles.
• hyperpack: exact packing and clearance consumers.
• hyperevolution: proposal/search layer for curve or layout candidates that still require exact validation.
• hyperdrc: PCB checks that use native curve, contour, and region objects instead of resolving topology with local float tolerances.

Typical Curve Problems

Curved planar geometry combines robust-predicate failures with representation failures: tangent contacts, overlapping arcs, nearly coincident boundaries, Bezier roots, offset self-intersections, and lossy chordization. Fixed epsilons can make one fixture pass and the next fail; eager exact algebra can also expand before broad-phase filters eliminate obvious misses.

hypercurve stages the work. Native curve objects keep exact control structure, prepared views and boxes reduce candidate sets, low-degree exact cases are promoted when available, and unresolved tangent, overlap, root-isolation, trimming, or topology cases remain explicit uncertainty instead of being hidden behind display polylines.

Main Types

• Point2, LineSeg2, CircularArc2, Segment2, CurveString2, Contour2, Region2, and RegionView2 are the main planar geometry objects.
• QuadraticBezier2, CubicBezier2, RationalQuadraticBezier2, and their fact, relation, metric, zero-error fitting, staged offset, and flattening APIs represent polynomial and rational curve work.
• Aabb2, prepared line/arc/curve-string/contour/region views, and segment/region fact types preserve repeated-query structure.
• Boolean, event, fragment, split, and boundary-loop types describe staged region boolean assembly.
• CurvePolicy, Classification<T>, and uncertainty enums make exact, unresolved, and adapter-facing decisions explicit.
• Finite projection, reconstruction, bulge, and display/certified polyline types define IO and display boundaries.

Precision Model

Native geometry uses Real coordinates. Primitive floats appear only in named finite projection, reconstruction, test, benchmark, rendering, or IO helpers. Bulge imports, flattened polylines, display offsets, and finite projections use explicit types so callers can tell whether they are using topology evidence or display geometry.

The crate promotes exact low-degree evidence where it can: line/arc relations, selected Bezier roots, retained intersection-region shape/refinement/isolation facts, monotone graph ordering, exact area and moment contributions, length intervals, zero-error line/arc and Bezier/conic primitive-fit evidence, exact Bezier area/moment prefix sums for repeated path-range queries, exact-parameter Bezier/conic split materialization, and retained branch-free Bezier/conic arrangement traversal with exact tangent-ordered successor selection for simple branch vertices. Closed retained traversals can materialize native Bezier/conic boundary regions; polynomial Bezier loops expose exact signed area while rational conic area remains explicit unsupported. Algebraic split boundaries are carried as certified unresolved fragments until the scalar layer can materialize true algebraic root endpoints. Cases that need overlap or same-tangent degeneracy traversal, retained-region role assignment, a more complete root solver, bounded higher-order fit, or offset trimming return unresolved regions, exact bisection or target-width isolation results, or explicit uncertainty.

Performance Model

hypercurve avoids numerical explosion by keeping curve objects native and using structure before generic algebra. Bounding boxes, segment kind, endpoint equality, monotone spans, material/hole role, prepared views, low-degree dispatch, dyadic candidate promotion, and source metadata all reduce the number of exact predicates and root checks.

Prepared curve-string, contour, and region views cache conservative boxes and predicate handles for repeated containment, self-contact, event, and boolean-boundary queries. Benchmarks track ordinary, prepared, and mixed-prepared paths so exactness work can be optimized where it matters.

Current Status

Implemented today:

• exact point, line-segment, circular-arc, bulge, curve-string, contour, region, and bounding-box APIs;
• polynomial quadratic/cubic Bezier and rational quadratic/conic objects with structural facts, evaluation, subdivision, certified bounds, monotone spans, graph-order predicates, retained intersection-region refinement/isolation helpers, and exact low-degree relation fast paths;
• intersection surfaces for line/line, line/arc, arc/arc, Bezier contact cases, curve strings, contours, regions, and prepared repeated-query views;
• signed area, area moment, length interval, flattening, and zero-error primitive fitting for Bezier/conic line and point images;
• staged Bezier/conic offset candidates that construct exact line-image offsets and leave free-form offsets unresolved until certified trimming/fitting exists;
• primitive line/arc offsets, checked offsets, cap styles, region event/fragment extraction, boolean-boundary assembly, and conservative unresolved states.

Known limits: shared-boundary overlap beyond certified fast paths, full Bezier/rational root isolation, NURBS, and offset self-intersection trimming remain future work.

Installation

[dependencies]
hypercurve = "0.2.0"

For sibling checkouts:

[dependencies]
hypercurve = { path = "../hypercurve" }

Feature summary:

• predicates: default feature enabling hyperlimit predicate integration.
• serde: enables serialization for public records that support it.

Usage

The native API uses hyperreal::Real coordinates:

use hypercurve::{CurvePolicy, LineSeg2, Point2, Real};

fn main() -> hypercurve::CurveResult<()> {
    let segment = LineSeg2::try_new(
        Point2::new(Real::from(0), Real::from(0)),
        Point2::new(Real::from(1), Real::from(0)),
    )?;

    let side = segment.classify_point(
        &Point2::new(Real::from(0), Real::from(1)),
        &CurvePolicy::certified(),
    );

    assert!(matches!(side, hypercurve::Classification::Decided(_)));
    Ok(())
}

Use native curve objects for Bezier facts, contours, regions, and downstream geometry work:

use hypercurve::{
    Contour2, CurvePolicy, LineSeg2, Point2, QuadraticBezier2, Region2, Segment2,
};
use hyperreal::Real;

let p = |x, y| Point2::new(Real::from(x), Real::from(y));
let bezier = QuadraticBezier2::new(p(0, 0), p(1, 2), p(2, 0));
let facts = bezier.structural_facts();
assert_eq!(facts.degree, hypercurve::BezierDegree::Quadratic);

let bottom = Segment2::Line(LineSeg2::try_new(p(0, 0), p(2, 0))?);
let right = Segment2::Line(LineSeg2::try_new(p(2, 0), p(2, 2))?);
let top = Segment2::Line(LineSeg2::try_new(p(2, 2), p(0, 2))?);
let left = Segment2::Line(LineSeg2::try_new(p(0, 2), p(0, 0))?);
let contour = Contour2::try_new(vec![bottom, right, top, left])?;
let region = Region2::from_material_contours(vec![contour]);

let location = region.classify_point(&p(1, 1), &CurvePolicy::certified())?;
assert!(matches!(location, hypercurve::Classification::Decided(_)));

Development

Useful local checks:

RUSTDOCFLAGS=-Dwarnings cargo doc --no-deps
cargo run --manifest-path examples/hypercurve_ui/Cargo.toml
cargo check --manifest-path examples/hypercurve_ui/Cargo.toml --target wasm32-unknown-unknown
cargo bench --bench containment
cargo bench --bench intersection
cargo bench --bench offset
cargo bench --bench reconstruction
cargo bench --bench svg_io --features svg

References

Bentley, Jon Louis, and Thomas A. Ottmann. “Algorithms for Reporting and Counting Geometric Intersections.” IEEE Transactions on Computers, vol. C-28, no. 9, 1979, pp. 643-647.

de Casteljau, Paul. “Outillage methodes calcul.” Andre Citroen Automobiles SA, 1959.

de Berg, Mark, et al. Computational Geometry: Algorithms and Applications. 3rd ed., Springer, 2008. https://doi.org/10.1007/978-3-540-77974-2.

Farouki, Rida T., and C. Andrew Neff. “Analytic Properties of Plane Offset Curves.” Computer Aided Geometric Design, vol. 7, nos. 1-4, 1990, pp. 83-99.

Farouki, Rida T., and V. T. Rajan. “Algorithms for Polynomials in Bernstein Form.” Computer Aided Geometric Design, vol. 5, no. 1, 1988, pp. 1-26.

Farin, Gerald. Curves and Surfaces for Computer-Aided Geometric Design: A Practical Guide. 5th ed., Morgan Kaufmann, 2002.

Foster, Erich L., Kai Hormann, and Romeo Traian Popa. “Clipping Simple Polygons with Degenerate Intersections.” Computers & Graphics: X, vol. 2, 2019, article 100007. https://doi.org/10.1016/j.cagx.2019.100007.

Greiner, Gunther, and Kai Hormann. “Efficient Clipping of Arbitrary Polygons.” ACM Transactions on Graphics, vol. 17, no. 2, 1998, pp. 71-83. https://doi.org/10.1145/274363.274364.

Hobby, John D. “Practical Segment Intersection with Finite Precision Output.” Computational Geometry, vol. 13, no. 4, 1999, pp. 199-214. https://doi.org/10.1016/S0925-7721(99)00021-8.

Hormann, Kai, and Alexander Agathos. “The Point in Polygon Problem for Arbitrary Polygons.” Computational Geometry, vol. 20, no. 3, 2001, pp. 131-144. https://doi.org/10.1016/S0925-7721(01)00012-8.

Kåsa, I. “A Circle Fitting Procedure and Its Error Analysis.” IEEE Transactions on Instrumentation and Measurement, vol. IM-25, no. 1, Mar. 1976, pp. 8-14. https://doi.org/10.1109/TIM.1976.6312298.

Martinez, Francisco, Antonio J. Rueda, and Francisco R. Feito. “A New Algorithm for Computing Boolean Operations on Polygons.” Computers & Geosciences, vol. 35, no. 6, 2009, pp. 1177-1185. https://doi.org/10.1016/j.cageo.2008.08.009.

Menger, K. “Untersuchungen über allgemeine Metrik.” Mathematische Annalen, vol. 100, 1928, pp. 75-163. http://eudml.org/doc/159284.

Schneider, Philip J., and David H. Eberly. Geometric Tools for Computer Graphics. Morgan Kaufmann, 2002.

Sederberg, Thomas W., and Tomoyuki Nishita. “Curve Intersection Using Bezier Clipping.” Computer-Aided Design, vol. 22, no. 9, 1990, pp. 538-549.

Shewchuk, Jonathan Richard. “Adaptive Precision Floating-Point Arithmetic and Fast Robust Geometric Predicates.” Discrete & Computational Geometry, vol. 18, no. 3, 1997, pp. 305-363. https://doi.org/10.1007/PL00009321.

Tiller, Wayne, and Eric G. Hanson. “Offsets of Two-Dimensional Profiles.” IEEE Computer Graphics and Applications, vol. 4, no. 9, 1984, pp. 36-46. https://doi.org/10.1109/MCG.1984.275995.

Vatti, Bala R. “A Generic Solution to Polygon Clipping.” Communications of the ACM, vol. 35, no. 7, 1992, pp. 56-63. https://doi.org/10.1145/129902.129906.

Yap, Chee K. “Towards Exact Geometric Computation.” Computational Geometry, vol. 7, nos. 1-2, 1997, pp. 3-23. https://doi.org/10.1016/0925-7721(95)00040-2.
